Blackmagic Design Mini Converter Audio to SDI 4K
The Blackmagic Design Mini Converter Audio to SDI 4K allows you to embed 4 channels of analogue audio and 8 channels of AES/EBU digital audio into any SDI video connection. It can be used to embed professional audio from devices like analogue decks and audio mixers into SDI video connections to use with SDI decks and routers. It helps add extra audio channels to video converters and maintains the resolution of the original input source.
Blackmagic Design Mini Converter Audio to SDI 4K Key Features:
- Used to embed professional audio from audio mixers or decks into SDI video connections
- Features a 6G-SDI input to accept Ultra HD and DCI 4K resolutions
- Provides four 1/4” audio jack connectors for inputting the audio channels
- Maintains the frame rate and resolution of the original input source
- Supports UHD and DCI 4K resolutions at up to 30 fps
- Can automatically detect and switch between the different signal formats
- Includes a redundant SDI input as an optional backup if the main SDI input is lost
- Includes a redundant SDI input as an optional backup if the main SDI input is lost
- Offers 4:2:2 and 4:4:4 sampling and colour precision
- Supports updates and configuration via USB 2.0 high speed
- Can detect between the SD, HD and 6G-SDI signal formats
- Includes built-in DIP switches to control the settings
- Includes software for Mac OS and Windows computers
FAQs:
What is the power supply required for the converter?
The mini converter requires a 12 VDC power supply with a supported operational range of 12 V – 31 V.
Can it be used to convert audio back to analogue?
This converter is only used to convert analogue signals to digital. It embeds audio onto the video signal and a separate de-embedder can be used to convert audio back to analogue.
Can it detect different signal formats?
This converter automatically detects SD, HD, 2K, UHD, and 4K signals. It detects and automatically switches between the formats.
What is the redundant SDI input for?
It includes a redundant SDI input as a backup option for when the main SDI input is lost. It enables you to run a second SDI cable and comes in handy during outdoor usage where there’s a chance that the cables might get damaged.
What are the environment specifications and how much does it weigh?
This converter weighs around 216 grams and the compact structure allows you to use it anywhere. It is recommended to use the converter at an operating temperature of 0-degree to 40-degree Celsius and 0% - 90% non-condensing relative humidity.
Product Specification
| Type | Micro Converter |
